NEWS
Definition of Injection Mold The mold used in plastic injection molding is called injection mold. The injection mold can make complex shape, high dimensional accuracy or with inserts plastic product at one time. The injection mold quality has a great influence on the plastic product quality. Structure and Composition of Injection Mold Main Formed Parts Injection Mold consists of core, cavity, screw, inserts and so on. 2. Gating System It is a channel that leads molten plastic from the nozzle of the injection machine to the closed mold cavity, usually consisting of main runner, branch runner, sprue gate and a cold slag. 3. Guiding Fitting To ensure the movable plate and the fixed plate can be accurately aligned when the movable plate is closed, the guide fitting plays the role of guiding and positioning. It is composed of guide pillar and guide sleeve, and some molds are also equipped with guide fittings on the ejector plate to ensure the smooth and reliable operation of the demolding mechanism. 4. Demoulding Structure There are many structural forms to demould. The most commonly forms are ejector rod, push pipe, ejector plate, rotary ejection and pneumatic ejection. Generally, it consists of ejector rod, reset rod, the ejector rod fixing plate, the ejector plate (ejector ring) and the ejector plate guide pillar / guide sleeve, etc. 5. Core-pulling Mechanism For plastic parts with side holes and side concave, before being ejected and demoulded, the sliders must be separated by side core pulling (lateral parting) before they can be demolded smoothly. 6. Mold Temperature Control System To meet the mold temperature requirements, a mold temperature adjustment system is required. Such as cooling water, hot water, hot oil, steam, cold air and electric heating systems to adjust the mold temperature. 7. Exhasut Air System To discharge the gas from mold, the exhaust groove is oftenly set at the mold parting surface. The gap between the push rods and other movable parts also play the role of exhaust gas. 8. Other Parts To complete the mold structure, it also need fixed plate, movable/fixed die plate, support pillar, support plate and connecting screw etc.

2022-09-21

PET Preform Blowing Machine Trouble Shooting Fault 1: Poor transparency Reasons: 1. Heating temperature is too high 2. Heating time is too long 3. Compressed air contains moisture 4. Preform with poor transparency 5. preform design problem 6. The inflation ratio is too small Methods: 1. Cool down 2. Shorten the heating time 3. Use a dryer to remove water 4. Improve preform quality. Select dry raw materials 5. Improve preform size design 6. Reduce preform diameter Fault 2: Pearly whitening appears in PET bottles Reasons: 1. The heating temperature is too low 2. Preform wall thickness is uneven 3. Preform wall is too thick. Insufficient heating. Methods: 1. Warm up or slow down the revolution speed 2. Improve preform quality 3. Reduce the preform thickness Fault 3: Bottom center offset Reasons: 1. Start blowing too early 2. The stretch rod did not go down to the bottom 3. Stretching rod and bottle shaft center are not in the same line 4. Uneven wall thickness of preform or uneven injection density 5. Uneven heating Methods: 1. Delay the blowing time/ increase the descending speed of the stretching rod 2. Adjust the position of the magnetic switch 3. Adjust the position of the stretching rod 4. Improve preform quality 5. Improve heating conditions/check if there is any problem with preform rotation Fault 4: Uneven wall thickness of PET bottles Reasons: 1. The position of the stretching rod is not in the preform center 2. The blowing holes are asymmetrical and have different apertures 3. The stretching ratio is too low /the inflation ratio is too small 4. The preform does not rotate in heater 5. Uneven wall thickness of preform/uneven injection density Methods: 1. Adjust the position of the stretch rod 2. Adjust the position and diameter of the blowing hole 3. Increase the stretching ratio/inflation ratio 4. Check the rotation device 5. Improve preform quality Fault 5: The upper part of the bottle is too thick Reason: 1. The upper temperature is too low 2. The position of the mold exhaust hole is too far from the upper part 3. The stretching ratio is too low 4. The upper part inflation ratio is too low 5. The speed of the stretching rod is too slow Methods: 1. Upper heating 2. Adjust the position of the exhaust hole 3. Increase the stretching ratio 4. Change bottle shape 5. Adjust stretch rod speed Fault 6: The bottle bottom is too thin Reasons: 1. Start blowing too early 2. The bottom temperature is too high 3. The preform bottom is too thin Methods: 1. Delay the start of the blowing time 2. Lower the bottom temperature 3. Increase preform bottom thickness Fault 7: The bottle moulding line is obvious Reasons: 1. The clamping pressure is not enough 2. The sealing time is too early 3. Mold problem 4. The preform neck size does not match with the mold Methods: 1. Increase the clamping pressure and adjust the angle of the clamping struts (<5 degrees) 2. Move back the position of the mold clamping travel switch 3. Repair the mold or check the assembly position of the mold, such as whether the guide pillar is loose, or whether the mold is not pressed tightly 4. Revise the mould neck

2022-05-12

PET Bottle Preform is popular in different kind of fields. Such as food & beverange, pharmaceutical & liquor, costmetic etc. Application for water bottles, carbonated bottles, edible oil bottles, food packaging, juice bottle and so on. Different field, the neck standards are different. The below PET bottle preform neck size for your reference. If you need any equipment about PET Preform Mould and PET Blowing Machine, Pls do not forget to contact with Winiber! We are specializing in Bottle Production Line!

2022-04-21

Here are some Safety operation rules for Blow molding machine: <1> Before starting each shift, add lubricating oil to each moving part. (manipulator, manipulator guide rail, mold opening and closing guide rail) <2> The swing arm 3-4 days/time. The large chain and small chain of the heating machine one time/month. Always check whether the main engine reducer and the heating machine reducer are short of oil. The main engine bearing can be every 3 months per time. The above suggestions are only for semi-autimatic blow molding machine. The automatic blow molding machine has automatic lubrication oil device. <3> Before production, check whether the moving parts are firm, whether the screws are loose or falling off, especially in places with strong impact force, and whether the belt transmission part is abnormal. <4> When start machine, start motor first, after 30 seconds to start the heating part to prevent voltage fluctuations.Turn on cooling water before starting the heating. <5> Check whether each emergency stop switch, safety door switch, and detection switch of the protection device are normal. <6> Check the peform in, preform out and insert preform part. <7> Check whether the lamp tube damages or breaks. Change it in time. <8> Check whether each pneumatic component is leaking and whether the action is sensitive. <9> Check whether the triplet abnormally leaks and blocks. <10> Clean solenoid valve if abnormal. <11> Clean and polish blowing mold regularly. <12> To prevent the dirt blowing into valve, you must move slowly when opening the high and low pressure air source switch. At the same time, open the exhaust valve for 30 seconds to ensure air is clean. <13> When starting the fully automatic blow molding machine, make sure that the mechanical parts are in good condition, no person and no foreign matter inside. Close the safety door. <14> Check high-pressure air source, low-pressure air source, power supply and water source. <15> After starting heater 2-3 minutes, oven temperature rises evenly. Press the preform in button.

2022-02-25

According to air compressor principles, there are piston compressor, rotary compressors (turbine, water ring, turbine) compressors, axial compressors, jet compressors and screw compressors, etc. The most widely used are piston compressor. How are piston compressors classified? ♦According to the cylinder position: (1) Horizontal compressor (2) Vertical compressor (3) Angle compressors ♦According to the number of cylinder sections: (1) Single-stage air compressor : the gas compressed one time in the cylinder (2) Double-stage air compressor: the gas compressed twice in the cylinder (3) Multi-stage air compressor: the gas compressed multiple times in the cylinder ♦According to the arrangement of the cylinders: (1) Tandem compressor: same shaft with several cylinder (2) Parallel compressor: everal cylinders in parallel on several shafts (3) Duplex compressor: a multi-stage compressor composed of a series and a parallel type (4) Symmetrical Balanced Compressor: The cylinders are arranged horizontally on both sides of the crankshaft where the crankshaft journals are 180 degrees from each other, and are arranged in an H-shape, and their inertial forces can basically be balanced. (Large compressors are all headed in this direction). ♦ According to the compression action of the piston: (1) Single-acting compressor: the gas compressed on one side of the piston (2) Double-acting compressor: gas can be compressed on both sides of the piston (3) Multi-cylinder single-acting compressor: one side of the piston is used for compression (4) Multi-cylinder double-acting compressors: compressors with multiple cylinders use both sides of the piston for compression. ♦According to the final exhaust pressure of the compressor: (1) Low pressure air compressor: the final exhaust pressure is 3~10 gauge pressure (2) Medium pressure compressor: the final exhaust pressure is 10~100 gauge pressure (3) High-pressure air compressor: the final exhaust pressure is 100~1000 gauge pressure (4) Ultra-high pressure air compressor: the exhaust end is above 1000 gauge pressure ♦According to the size of the compressor displacement: (1) Micro compressor: below 1m³/min (2) Small compressor: below 1~10m³/min (3) Medium-sized compressor: below 10m³~100m³/min (4) Large compressor: 100m³ ♦According to the speed: (1) Low-speed compressor: below 2000 rpm (2) Compressor with intermediate speed: at 200~450 rpm (3) High-speed compressor: 450~1000 rpm ♦ According to the type of transmission: (1) Electric compressors: those powered by electric motors (2) Pneumatic compressors: those powered by steam engines (3) Compressors powered by internal combustion engines (4) Compressor powered by steam turbine ♦According to the cooling method: (1) Water-cooled compressor: use the circulating flow of cooling water to conduct away the heat given in the compression process (2) Air-cooled compressor: use its own wind power to conduct heat during the compression process through the heat sink ♦According to the transmission method: (1) Install the rigid body coupling to directly drive the compressor or close to the compressor (2) Direct drive compressor with flexible coupling (3) Reduction gear drive compressor (4) Belt (flat belt or V-belt) drive compressor (5) Free piston compressor without crankshaft-connecting rod mechanism (6) Compressor with positive structure – the motor cylinder of the motor compressor and the compressor seat are integrally made, and the compressor uses a common crankshaft Whether air mixed with lubricating oil, air compressor can be divided into oil-type and oil-free type. Lubricating oil has the function of lubricating and cooling any mechanical equipment. It also has an air-tight effect to improve the volumetric efficiency. The effiency is definitely higher than oil-free. It is undeniable that the oil and gas will cause a lot of troubles in use. Even if it is processed by precision filters, it cannot achieve a safe and oil-free state. Although the energy efficiency of an oil-air compressor is higher, the cost of the precision filter are also considerable.

2022-02-17

PET is one of the most popular material in packaging fields. PET plastic bottle is widely used in water, carbonated drinks, pharmaceutical and personcal care applications. What is the advantage to use PET Plastic Bottles? 1. Easy Transportation & Flexible Design : PET plastic bottles require less protection during transportation. This can help manufacturers save on cost with simple package. Furthermore, PET bottles has endless possibilities when it comes to design. Only change the bottle moud. It can get different form and size. Also bottle mould price is not high. This enables factories to create their own identity and come up with unique designs. 2. Better Hygiene: FDA has cleared PET plasti bottles for single and repeated use. Regulatory authorities has tested the new and re-used PET bottlesfor harmful substances. It shows ir is hygienic and incredibly resistant to micro-organisms. Moreover, it will not chemically or biologically degrade as it does not react with food and beverages. 3. Recyclable: PET plastic is 100% recyclable and easy to recycle because at low temperature the polymer chain breaks down. The polymer chain does not undergo degradation during the recycling process. According to PLANT Apothecary, recycled PET plastic has been proven it does not leach harmful chemicals into the products it contains. Are you considering to Start your business with PET plastic bottles? If yes, Pls contact with us now! Winiber, we are the great supplier of PET Bottle Blowing Machine, PET Preform Mould and PET Bottle Mould! Join With Us!

2022-01-20

PET Preform is commonly used for food & beverage, cosmetic, pharmaceutical & liquor bottle. Application for water bottles, CSD, edible oil, food packaging, juice and alcoholic beverages. PET preform are made by injection molding of polyethylene terephthalate, which is the most common thermoplastic polyester. PET is strong, stiff, hard, and dimensionally stable material. It is resistant to water, gas, and all the chemicals except alkalis. PET is colorless and highly transparent. It is popular in Food and beverages industries. PET products with the advanatge of light weight, long shelf life and easy to handle. It is also popular in healthcare and cosmetics industries. Demand for pack weight reduction, rise in consumption of carbonated soft drink, and new product developments are some of the major drivers for the growth of PET preform market. Stringent government regulations on usages of plastic products and unavailability of recycling facilities are major restraint for PET preforms market. PET preform Market Classfication: On the basis of End-Use Industry: Food and Beverage Industry Cosmetics Industry Pharmaceutical & Liquor Industry Bottle Industry On the basis of applications: Water bottles Carbonated Soft drink (CSD) bottles Oil/Edible oil bottles Food packaging Juice/ Milk bottles Alcoholic Drinks Bottles Others (Chemicals, Pesticides, Households etc.) On the basis of neck standards: PCO 28/410 29/21 29/25 30/25 48/41 38 mm 48 mm 52 mm Winiber can make different types of high quality preform mould to meet customer`s requirement. Move your fingers to Contact with us!

2021-11-29

Winiber provides high speed automatic PET preform molding production line for PET bottle packaging industry. It includes different standards from 4 cavities to 72 cavities. Our PET preform mold adopts hot runner valve gate system. With the characteristics of high production efficiency, excellent product performance, stable production and high mold precision. Help customers to save production efficiency, improve supply capacity and increase profits. PET preform production line fits to international standards. PET preform injection molding machines 1. PET special screw and barrel. 2. Bigger injection capacity can meet the requirements of PET injection pressure. 3. Servo system to support high injection weight. 4. Hydraulic motor can provide greater torque for the machine to meet the particularity of PET material. 5. Oil pump, servo motor and servo driver, reasonably control cycle time. Winiber not only provides an injection molding machine and a plastic mold, but also the one-stop turnkey solution line. If you have any requirements for PET preform molding production line, welcome to contact us! We will support on your PET preform projects and give you a qualified and satisfied production line.

2021-11-19

What affect PET plastic bottle quality? Preform quality Recycling materials should not exceed 10%. The number of recycling time should not exceed two. Preform cools for more than 48 hours. Storage time can not exceed 6 months. We can not mix different production dates preform, especially preforms with too long storage time PET Plastic Bottle Machine Pre-heating The PET Plastic Bottle Machine heating temperature usually set at 85-120℃. Transparent preform should be higher, and the colored preform should be lower. Too high or too low will cause product defects, such as tearing, white fog, etc. Each area has indepent temperature controller. The output power has a great influence on the heating preform, which controls the heat output of the entire oven. When the machine turns off for a long time and turns on again, the initial output power should be set higher accordingly. Then gradually reduce to the normal state. The output power is generally about 80%. PET Plastic Bottle Machine Pre-blowing PET Plastic Bottle Machine Pre-blowing makes the preform take a genral shape and increase its longitudinal strength by the stretching rod. If the pre-blowing position is advanced, bottle bottom will be skewed , thin, uneven and white. Inversely, bottle center will be thickr and sink. singel-way valve controls air flow. Generally 3-4 turns are appropriate. The pre-blowing pressure should be 0.8-1MPa. Bottle bottom and center point has the greatest impact on the quality of the bottle. Improper adjustment often causes fatal defects such as bottle burst (under normal experimental conditions) and leakage. stretching rod The stretching rod must move vertically and steadily during the blowing process. Driving pressure 0.55-0.8MPa. Gap with the bottom mold 2.3-2.5mm. If the gap is too large, the center point will shift; if the gap is too small, the center point will become thinner. High-pressure blow The high-pressure blowing pressure is generally 3.7-4MPa. There are two positions,high pressure gas and exhaust. The length of this time has a great influence on the stability of the bottle volume. Insufficient high-pressure air may cause improper bottle molding and insufficient bottom blowing. Bottle mould During the production process, keep the mold constant temperature, clean, and unblocked vent. When the mold heating and cooling system fails, the bottle neck will be tilted. The volume and height will change, and the bottom will become heavier. Maintaining the mold constant temperature can also prevent condensation on the mold surface. After PET molding, the shrinkage rate is relatively large, generally 1.8%, and it is slightly reduced after adding glass fiber reinforcement, but it still reaches 0.2%-1.0%. Under normal circumstances, high mold temperature shrinkage rate is large, low mold temperature shrinkage rate is small, in order to maintain the stability of PET bottle volume, mold temperature must be strictly controlled. Generally, the temperature of the bottle body is slightly higher, which is 20-45℃, and the bottom requirement is lower, which is 6-15℃. High bottom temperature will make the bottom heavier and the center point thicker. Experts of automatic blow molding machine concluded that there are nozzles in actual production that will affect the forming of PET bottles.

2021-09-07

The difference between PET plastic bottle blowing machine and extrusion blow molding machine: PET plastic bottle blowing machine is mainly for PET bottles. The semi-automatic custom made PET blowing machine can do some simple PP bottles, like the feeding-bottle. Extrusion blow molding machine is a device for blowing hollow plastic product, the material like HDPE, PP, PC and PVC. PET plastic bottle blowing machine has 2 types, two-steps and one-step. The most in market is two-steps. Injection machine makes the preforms from material, then PET blowing machine blow the preform to bottles. The one-step blowing machine is to inject molding at one time in same machine. Extrusion blow molding machine also named based model forming. The resin through the loader to barrel, then push to die head mould. After cooling becomes to bottles. Choose your right blowing machine, choose Winiber!

2021-07-28
